  • 136 kg user weight capacity
  • 270 W smooth and powerful motor
  • AGM Battery 24V12Ah
  • 8 km/h Max. speed (driving forward)
Category: Tags: , , , ,

Description

The Equinox Travel by Icon Rehab exemplifies innovation in portable mobility solutions, offering freedom and convenience in a remarkably compact design. This intelligently engineered scooter disassembles into five lightweight components, making it the perfect companion for both daily activities and travel adventures.

What makes this different?

The Equinox Travel stands out with its dual 270W motors delivering smooth, efficient performance, while its advanced suspension system and puncture-proof tyres ensure a comfortable journey on various surfaces. The ingenious design allows for both on-board and off-board battery charging, with flexible options of 20AH for extended trips or 12AH for shorter excursions.

Why do we like it?

The Equinox Travel excels in user-friendly operation with its intuitive controls, featuring a featherlight “wig wag” lever for seamless movement and a practical freewheel mode for manual operation when needed. The thoughtful design prioritizes both portability and performance, making it equally suitable for spontaneous outings and planned adventures.

Features

  • Feather-touch disassembly breaks the scooter into 5 lightweight parts.
  • Total assembled weight: only 44 kg.
  • Non-marking, anti-scuff, puncture-proof 8-inch tires.
  • Striking triple-spoke alloy wheels.
  • Top speed: 4 mph (6.4 km/h).
  • Long battery life: travel up to 10 km on a single charge.
  • Front tiller-mounted basket for carrying shopping or personal items.
  • User weight capacity: 136 kg (21.4st).
  • Dual 270W motors that are smooth, powerful, efficient, and reliable.
  • Freewheel mode for easy manual pushing.
  • Auto-shutdown feature after 15 minutes of inactivity to conserve battery.
  • “Off-board” remote charging.
  • 20Ah lithium-ion battery.
  • Forward and reverse motion control via a featherlight “wig-wag” lever.
  • Comfortable seat with a super-soft foam base.
  • Backrest featuring a durable and waterproof outer layer.
  • Seat slides forward and backward and rotates 180 degrees.
  • Width-adjustable, flip-up armrests.
  • Large rear light reflectors for enhanced visibility.
  • Optional wing mirrors for better awareness of hazards behind you.
  • Push-button horn to alert pedestrians or others.
  • Anti-tip wheels to prevent tipping and protect the drive motors.
  • Microprocessor-based control panel for optimal power management.

Specifications

Type  Scooter, rear-wheel drive, Class A
Max. user weight 136 Kg
Max. speed (driving forward) 8 km/h
Dimensions unfolded (L x W x H)  1030 x 490 x 880 mm
Motor 270-Watt
Mileage 15 km
Battery AGM Battery 24V12Ah
Weight of battery 9 Kg
Brake Electromagnetic brake
Total weight (battery included) 43.5 Kg
Maximum weight of single part 15 Kg (Front frame assembly)
Maximum height of obstacle 45 mm
Maximum safe slope 6 degrees
Minimum turning radius 1150 mm
Minimum width required to reverse 1250 mm
Effective seat depth 370 mm
Effective seat width 410 mm
Seat surface height at front edge 380 mm
Height of footplate 110 mm
Angle seat surface -8 degrees
Max. sound level scooter motor 68 dB
Diameter rear wheels (number) 8 x 2.5 inch
Diameter front wheels (number) 8 x 2.5 inch
Battery charger Input: 100-240V AC, 50-60Hz, 1.2-0.5A, Class II. Output: 24V DC, 2.0A
Min. braking distance at max. speed 1500 mm
Control (wig-wag) Lever to start/stop movement
Operating console Rotatable switch for speed control
Controller Dynamic 50A
Protection class IP X5
